General Specifications:

• Engine Type: 4-stroke diesel
• Configuration: Inline 6 cylinders
• Displacement: 8.3 liters (505 cubic inches)
• Bore x Stroke: 114 mm x 135 mm (4.49 inches x 5.32 inches)
• Aspiration: Turbocharged and aftercooled
• Cooling System: Heat exchanger with seawater cooling

Performance:

• Maximum Power Output:
  • 493 hp (368 kW) @ 3000 RPM
  • 500 hp (373 kW) @ 2800 RPM
• Continuous Power: Typically around 430-450 hp (320-336 kW)
• Torque: Up to 1696 Nm (1250 lb-ft) @ 1400 RPM

Fuel System:

• Fuel Type: Diesel
• Fuel Injection System: High-pressure common rail (HPCR)

Dimensions and Weight:

• Length: Approx. 1282 mm (50.5 inches)
• Width: Approx. 767 mm (30.2 inches)
• Height: Approx. 1024 mm (40.3 inches)
• Dry Weight: Approx. 918 kg (2025 lbs)
